Johnson Controls VG7241CT+3008B Globe Valve

The Globe Valve Johnson Controls VG7241CT+3008B delivers precise, dependable flow control for hot water, chilled water, glycol solutions, and steam. This 1/2 inch, 2-way globe valve features a push-down-to-close actuation for reliable shutoff in HVAC and process applications, with a compact, robust design ideal for retrofit or new installations.

Constructed for durability, the valve uses a cast bronze body, brass bonnet and seat, stainless steel stem, and brass trim to resist corrosion in demanding environments. It carries a temperature rating of 35 to 284°F and a Class 250 pressure rating, meeting ASME B16.15 standards. The included Spring Pneumatic Actuator enables fast, smooth operation, while the 0.73 CV water flow coefficient supports precise throttling. The VG7241CT+3008B is suitable for hot water, chilled water, glycol solutions, and steam control.

• Actuation: Spring Pneumatic Actuator
• End Connection: Threaded
• Nominal Size: 1/2 inch
• Type: 2-Way Globe Valve
• Materials: Body Cast Bronze; Bonnet Brass; Stem Stainless Steel; Seat Brass; Trim Brass
• Temperature Range: 35–284°F
• Pressure: Class 250 (Close-Off 365 PSIG); Steam 38 PSIG; Spring 3–6 PSIG
• Standard: ASME B16.15
• Water Flow: 0.73 CV
