KMC Kreuter MEP-5223 Damper Actuator

The KMC Kreuter MEP-5223 Damper Actuator is designed for precise HVAC damper control, delivering reliable motion with direct coupled mounting. This compact unit measures 4 in width, 3-3/16 in depth, and 6-7/64 in height, and it provides a smooth 45-degree rotation for accurate airflow adjustment.

Key specifications include a 0.51 in shaft diameter, 10 in-lb torque, and a 240 VAC input. The plated screw terminal supports 14 to 22 AWG copper wire for secure wiring, while the operating temperature range of 32 to 140°F keeps dependable performance in varied environments. With timing of 15 seconds at 60 Hz and 18 seconds at 50 Hz, this actuator offers predictable cycling for reliable damper positioning.

• Direct Coupled Mounting for straightforward installation
• 45-Degree Rotation for precise airflow control
• 0.51 in Shaft Diameter ensures compatibility with standard linkages
• 240 VAC Input for reliable power supply
• 10 in-lb Torque delivers steady damper positioning
• Plated Screw Terminal for 14–22 AWG copper wire
• Temperature Range 32–140°F suitable for varied environments
• Timing: 15 s @ 60 Hz; 18 s @ 50 Hz for predictable cycles

Engineered for durable service in commercial or industrial HVAC applications, the MEP-5223 is a robust choice for accurate damper control.
