McDonnell & Miller 767 Boiler Low Water Cut-Off

The McDonnell & Miller 767 Boiler Low Water Cut-Off delivers essential boiler protection by monitoring water levels in steam systems. This float-type, lever/mechanical actuation device provides reliable shut-off to prevent damage from low-water conditions in residential and commercial boilers.

With a 2-1/2 inch threaded port connection and a compact 9-11/16 inch length, it fits a wide range of boiler configurations. It uses a float-type, lever/mechanical actuation to reliably shut off the boiler when water levels fall below the set point. It supports 120/240 Volt AC power and is rated for steam at up to 20 PSI, handling both steam and water media. The unit is UL, CSA, and FM listed, ensuring industry-standard safety and compatibility.

• Type: Float-type, lever/mechanical actuation
• Port Connection: 2-1/2 inch threaded
• Length: 9-11/16 inch
• Electrical Ratings: 7.4 A @ 120V / 3.7 A @ 240V (full load); 44.4 A @ 120V / 22.2 A @ 240V (locked rotor)
• Input Supply: 120/240V AC, 125V Amp
• Pressure Rating: 20 PSI (Steam)
• Media Handled: Steam and water
• Applications: Residential and commercial
• Standards: UL, CSA, FM listed
