Resideo - Honeywell Home R841E1068 Heater Relay

Resideo - Honeywell Home R841E1068 Heater Relay

$245.00 USD
$245.00 USD
Sale Sold out
Shipping calculated at checkout.

Out of stock

2684

View full details

R841E1068 Heater Relay from Resideo - Honeywell Home is an AC-operated control designed for heating equipment. With a 24 Volt AC coil and SPST switch, this relay delivers dependable on/off control for baseboard, ceiling, cable, and duct heaters.

Built for durable HVAC duty, it includes an enclosure and an integral transformer for a compact, ready-to-wire solution. The unit is UL and CSA listed, ensuring safe installation in residential or commercial systems.

Designed for versatility in heating systems, the R841E1068 supports various load profiles with precise current ratings and reliable operation across temperatures.

  • Coil: 24V AC 50/60 Hz
  • Switch type: SPST
  • Full-load current: 7 A at 208/240/277 VAC; 14 A at 120 VAC
  • Locked-rotor current: 42 A at 208/240/277 VAC; 84 A at 120 VAC
  • Resistive current: 22 A at 120/208/240 VAC; 19 A at 277 VAC
  • Includes: 1/2" male conduit bushing, enclosure, integral transformer, dual-load
  • Applications: heating equipment, baseboard, ceiling cable and duct heater
  • Temperature range: -20 to 150°F
  • Certifications: UL and CSA listed

Specifications

TypeAC Operated
Temperature Rating-20 to 150 Deg F
Input Supply24 Volt AC 50/60 Hertz (Coil)
Current Rating7 Amp at 208/240/277 Volt AC and 14 Amp at 120 Volt AC (Full Load), 42 Amp at 208/240/277 Volt AC and 84 Amp at 120 Volt AC (Locked Rotor), 22 Amp at 120/208/240 Volt AC and 19 Amp at 277 Volt AC (Resistive)
ApplicationHeating Equipment, Baseboard, Ceiling Cable and Duct Heater
StandardsUL, CSA
Includes1/2 Inch Male Conduit Bushing, Enclosure, Integral Transformer, Dual Load
Actuation TypeElectric
Switch TypeSPST
