Resideo - Honeywell Home S87B1016 Ignition Control Module

Resideo - Honeywell Home S87B1016 Ignition Control Module delivers reliable, industry-grade direct-spark ignition for gas-fired furnaces, boilers, and heating appliances. Designed for natural gas or liquid propane, this module uses an internal high-voltage spark generator and a single-rod flame sense for fast, safe ignition with precise flame monitoring.

CSA-approved and built for rugged service, it supports 24V AC operation at 60 Hz and a compact size that fits standard mounting footprints. The unit combines durable ignition controls with quick re-ignition after a flame loss, helping minimize downtime in residential and commercial heating systems.

• Type: Direct Spark, Electronic, Pilot
• Fuel Type: Natural Gas / Propane
• Ignition Source: Internal High Voltage Spark Generator
• Ignition Sequence: 1-Trial
• Flame Sense: Single Rod
• Voltage & Power: 24V AC, 60 Hz
• Valve Rating: 2 Amp at 24V AC
• Temperature Range: -40°F to 175°F
• Applications: Gas Fired Furnace, Boiler, Heating Appliance
• Approval: CSA
• Lockout & Re-Ignition: 11-second lockout; 0.8-second flame re-ignition
• Includes: Alarm Terminal
• Dimensions: 4-1/16" W x 1-15/16" L x 5-1/4" H
