Resideo - Honeywell Home S87B1024 Ignition Control Module

Resideo - Honeywell Home S87B1024 Ignition Control Module is a high-reliability ignition control designed for gas-fired furnaces, boilers, and heating appliances. This direct spark, electronic ignition module supports pilot operation and uses an internal high voltage spark generator to deliver fast, dependable ignition in demanding applications.

Its compact 4-1/16" W x 1-15/16" L x 5-1/4" H footprint fits many residential and light commercial systems, and it operates across a wide temperature range from -40 to 175 °F. The module is designed for natural gas and liquid propane gas, featuring a single-rod flame sense and a 1-trial ignition sequence with a 21-second trial time for quick startup and solid reliability.

CSA-approved for safety, this ignition control includes an alarm terminal for enhanced protection and a precise flame failure re-ignition time of 0.8 seconds, ensuring continuous operation with minimal downtime.

• Type: Direct Spark, Electronic, Pilot
• Fuel Type: Natural Gas / Liquid Propane Gas
• Flame Sense: Single Rod
• Ignition Source: Internal High Voltage Spark Generator
• Ignition Sequence: 1-Trial (21 Second Trial Time)
• Flame Failure: 0.8 Seconds at 5 µA
• Valve Rating: 2 A at 24 V AC
• Power: 24 V AC, 60 Hz
• Size: 4-1/16" W × 1-15/16" L × 5-1/4" H
• Temperature Range: -40 to 175 °F
• Applications: Gas Fired Furnace, Boiler, Heating Appliance
• Approval: CSA
• Includes: Alarm Terminal
