Resideo - Honeywell Home S87B1065 Ignition Control Module

The S87B1065 Ignition Control Module from Resideo and Honeywell Home delivers reliable direct-spark ignition for gas-fired furnaces, boilers, and heating appliances.

This electronic ignition module supports natural gas and liquid propane gas, using a single-rod flame sense and an internal high voltage spark generator to ignite on the first try.

Designed for fast, safe operation with a 1-trial ignition sequence and a flame-failure response time of 0.8 seconds at 5 microamps, it helps minimize outages and wear on your system. Lockout timing is 4 seconds, and an alarm terminal is included for easy monitoring.

Key specifications ensure compatibility and durability: 24V AC, 60 Hz power, valve rating of 2 A at 24V AC, temperature rating from -40 to 175°F, and compact sizing of 4-1/16 in. W x 1-15/16 in. L x 5-1/4 in. H.

• Direct spark ignition with an internal high-voltage spark generator for reliable starts
• Supports natural gas and propane gas fuels
• Flame sense with single-rod sensor and fast flame failure detection
• 1-Trial ignition sequence and 0.8-second re-ignition response
• CSA approved with included alarm terminal for safety monitoring
