Resideo - Honeywell Home S87C1030 Ignition Control Module

The S87C1030 Ignition Control Module from Resideo - Honeywell Home delivers reliable direct spark ignition for gas-fired furnaces, boilers, and heating appliances. This electronic ignition module supports pilot operation and uses an internal high voltage spark generator for fast, safe ignition. With a two-rod flame sense, it detects flame quickly and responds to faults with precision. Ideal for natural gas or propane systems, it's engineered for durable performance in challenging environments.

CSA approved and designed for compact spaces, this ignition control fits tight installations while delivering consistent reliability across a wide temperature range.

• Direct Spark ignition with an internal high voltage spark generator for fast starts
• Electronic ignition with pilot operation support
• Flame sensing via two-rod flame sense for robust detection
• Power 24 Volt AC at 60 Hz
• Size 4-1/16" W x 1-15/16" L x 5-1/4" H
• Temperature range -40 to 175°F
• Applications gas-fired furnaces, boilers, and heating appliances
• Safety CSA approved with 21-second lockout timing
• Ignition performance 1-trial sequence; 21-second ignition trial
• Flame failure re-ignition in 0.8 seconds at 5 μA
