Resideo - Honeywell Home S87J1026 Ignition Control Module

The Resideo - Honeywell Home S87J1026 Ignition Control Module delivers reliable direct spark ignition for gas-fired furnaces, boilers, and heating appliances. This electronic ignition module supports natural gas and propane, featuring an internal high voltage spark generator, a single-rod flame sense, and a 1-trial ignition sequence for fast, dependable starts.

Built for safety and efficiency, it operates on 24V AC at 60 Hz with a 2A valve rating, and fits compactly (4-1/16" W × 1-15/16" L × 5-1/4" H). The CSA-approved unit provides robust protection, including an 11-second lockout and a flame failure response as quick as 0.8 seconds at 5 microamps, with rapid re-ignition to minimize downtime.

• Direct Spark ignition with internal high voltage spark generator
• Fuel flexibility: Natural gas and propane
• Flame sensing: single-rod flame sense for accurate detection
• Ignition sequence: 1-trial ignition, 11-second lockout, 30-second prepurge
• Electrical specs: 24V AC, 60 Hz, 2A valve rating
• Durability: -40 to 175°F operation, CSA approved
• Applications: gas-fired furnace, boiler, heating appliance
• Reliability: 0.8-second flame failure re-ignition
