Resideo - Honeywell Home S87J1034 Ignition Control Module

Ignition Control Module from Resideo - Honeywell Home S87J1034 delivers reliable direct spark ignition for gas-fired furnaces, boilers, and heating appliances. This versatile module supports direct spark, electronic, and pilot ignition and is designed for natural gas or propane fuel. With an internal high-voltage spark generator and a single-rod flame sensor, it delivers fast flame detection and safe shutdown if a flame is not sensed.

Designed for compact installations, this CSA-approved unit operates at 24V AC, 60 Hz, and provides a robust 2 Amp valve rating. Its precise timing—21-second ignition trial, 30-second prepurge, and quick flame-failure response—ensures reliable starts while protecting components.

• Type: Direct Spark, Electronic, Pilot
• Fuel Type: Natural Gas or Propane
• Flame Sense: Single Rod
• Internal High-Voltage Spark Generator
• Ignition Sequence: 1-Trial (21s Trial Time)
• Prepurge Time: 30 seconds
• Flame Failure: 0.8 seconds at 5 microamps; re-ignition in 0.8 seconds
• Power & Valve: 24V AC, 60 Hz; 2 A at 24V AC
• Size & Temperature: 4-1/16 in W x 1-15/16 in L x 5-1/4 in H; -40 to 175°F
• Applications & Approval: Gas-fired furnace, boiler, heating appliance; CSA approved

Choose the S87J1034 for dependable ignition control that guards against misfires and provides CSA-certified reliability in modern heating systems.
