Resideo - Honeywell Home S87K1008 Ignition Control Module

The S87K1008 Ignition Control Module is a reliable direct spark ignition solution for gas-fired furnaces, boilers, and heating appliances. This electronic, pilot-capable control supports natural gas and liquid propane and uses an internal high-voltage spark generator to reliably sense flame with a two-rod flame sensor. With multiple-trial ignition and a 4-second ignition sequence, it delivers fast, safe startup while the 30-second prepurge improves combustion quality.

• Ignition type: Direct spark with internal high voltage generator
• Fuel compatibility: Natural gas and liquid propane gas
• Flame sensing: Two-rod flame sense
• Ignition sequence: Multiple-trial ignition; 4-second ignition trial
• Prepurge: 30-second prepurge
• Flame safety: Flame failure response time 0.8 seconds at 5 microamps
• Re-ignition: 0.8-second re-ignition after flame loss
• Power & valve: 24 VAC, 60 Hz; valve rating 2 A at 24 V
• Size: 4-1/16 in W × 1-15/16 in L × 5-1/4 in H
• Operating range: -40 to 175°F
• Compliance: CSA approved
• Lockout: 4-second lockout timing
