Resideo - Honeywell Home SV9520M2536 Gas Control Valve

Gas Control Valve SV9520M2536 from Resideo Honeywell Home delivers reliable, code-tested control for gas-fired appliances. This standard-opening, straight-through valve is ideal for residential combustion control and commercial equipment, including rooftop furnaces, boilers, unit heaters, infrared heaters, and water heaters. With a 1/2 inch nominal size and threaded end connections, it fits a wide range of installations while maintaining a compact footprint and an end-to-end distance of 3.2 inches. It operates on 24 Volt AC at 50/60 Hz and tolerates -40 to 175 Deg F, making it suitable for demanding environments.

Includes a Natural to Liquid Propane Conversion Kit for versatile fuel options. CSA standard compliance ensures safety and reliability across your installation. The valve features direct hot surface ignition for fast starts, a flame failure response time of 2 seconds at 5 microamps, and an ignition trial time of 7 seconds with a 15-second prepurge. Capable of 20,000 to 200,000 BTU/hour, it also provides 1/8 inch pressure tapping and a regulator set point of 3.5 inches WC. Its compact overall dimensions are 4.1 inches long by 4.9 inches high, with mounting flexibility from 0 to 90 degrees vertical installation.

• Nominal size: 1/2 inch
• End connections: Threaded x Threaded
• Input supply: 24V AC at 50/60 Hz
• Temperature range: -40 to 175 Deg F
• Capacity: 20,000–200,000 BTU/hr
• Natural to propane conversion kit included
• Direct hot surface ignition
• Flame failure: 2 seconds at 5 microamps
• Ignition trial: 7 seconds; Prepurge: 15 seconds
• CSA standard compliant
