Resideo - Honeywell Home V800A1591 Combination Gas Control Valve

The V800A1591 Combination Gas Control Valve is a reliable, low-voltage control solution for residential gas-fired appliances. This Type 1-Stage, standing pilot valve operates on 24 Volt AC (60 Hz) to deliver precise residential combustion control. With a 3/4 inch nominal size and threaded end connections, it installs compactly in standard gas lines and supports safe operation in tight spaces. It’s UL and CSA approved and ships with a Natural to Liquid Propane Conversion Kit for versatile fuel compatibility.

• Type: Type 1-Stage, Low Voltage, Standard Opening
• Size & Connections: Nominal Size 3/4 Inch; End Connection Threaded x Threaded; End to End Distance 4-1/16 Inch; 1/4 Inch Quick Connect Male Terminal
• Electrical & Ignition: Input Supply Rating 24 Volt AC at 60 Hz; Ignition Type Standing Pilot; Safety Shut-Off
• Inclusions: Natural to Liquid Propane Conversion Kit; (2) 3/4 Inch x 1/2 Inch Reducer Bushing; 1/2 Inch Threaded Side Outlet; Manual Gas Valve; Single Millivoltage Automatic Operator; Pressure Regulator; Pilot Gas Filter and Flow Adjustment; Pressure Tapping; Thermocouple Connector; Pilot Flow Adjustment Screw; ECO Connector
• Performance & Standards: Capacity 335000 to 34000 BTU/Hour; Pressure Regulator Set Point 3.5 Inch WC; Pressure Tapping 1/8 Inch Threaded; Applicable Standard UL, CSA
• Installation & Orientation: Mounting 0 to 90 Degree Vertical Installation; Overall Dimensions Depth 3-3/16 Inch; Height 4-3/4 Inch
