Resideo - Honeywell Home V8043E5061 Motorized Zone Valve

V8043E5061 motorized zone valve from Honeywell Home delivers precise zoned heating control for hydronic systems. This 2-Way, straight-through valve uses a 3/4 inch nominal size with soldered end connections for a clean, compact install. The valve is normally closed and features a 2-Position, spring-return actuator for reliable open/close action.

Built for hot-water service, the brass body houses a stainless steel stem and EPDM packing with Buna-N ball plug for durable operation in demanding environments. It operates on low-voltage control (24V AC, 60 Hz) with an 18 inch lead and includes a SPST end switch and a manual opener for easy commissioning. The valve opens in about 15 seconds and delivers a flow capacity of 8 Cv, ensuring quick, balanced zone response.

• 2-Way, straight-through valve for precise hydronic zoning
• 3/4 inch nominal size with soldered x soldered end connections
• Normally closed, 2-Position, spring-return actuator with manual opener
• Brass body, stainless steel stem, EPDM packing, Buna-N ball plug for durability
• 24V AC control (0.32 A) with 18 inch lead; SPST end switch
• Open time ≈ 15 seconds; flow capacity 8 Cv; hot-water rated (50–200°F)
