Resideo - Honeywell Home VU443A1008 Valve Actuator

The VU443A1008 Valve Actuator from Honeywell Home by Resideo delivers precise valve control for your HVAC system. Engineered with a spring-return, SPST 2-Way design, it operates on 120V AC with a 6W driving power to reliably modulate flow. This rugged actuator is built to maintain accurate positioning and quick response in varying loads.

• Type SPST, 2-Way/Position with spring return for simple, reliable valve control in heating or cooling circuits.
• Voltage: 120V AC; Frequency: 60 Hz; Driving Power: 6W — compatible with standard control boards and thermostats.
• Rotation angle: 22 degrees of travel for precise valve modulation.
• Durable stainless steel body; supply connection via 6-inch wire lead for easy, secure wiring.
• Operating temperature range: 34–125°F (ambient); CSA-approved for safety and compliance in residential and commercial environments.
• Timing: 15 seconds from start to full travel for smooth, controlled actuation.

Designed to fit typical HVAC valve assemblies, the VU443A1008 combines durability with dependable performance, ensuring comfortable climate control and efficient system operation.
