Resideo - Honeywell Home ZD6X6TZ Zone Control Damper

The Zone Control Damper ZD6X6TZ by Resideo - Honeywell Home delivers precise airflow management for HVAC zoning. This Zone Control Damper uses a square, parallel blade design and a duct size of 6 Inch x 6 Inch, enabling efficient distribution of conditioned air to multiple zones. Crafted with an extruded aluminum blade, it stands up to daily use while maintaining smooth, quiet operation.

Engineered for reliability, the ZD6X6TZ offers fail-safe performance and normally open operation to ensure comfort and safety even during power interruptions. It operates on 24 Volt AC at 60 Hz with a compact 8 VA motor and 71 Inch-Ounce torque, and its 90-degree travel provides quick, decisive dampening. The motor mounting is side, and the device is designed for parallel blade dampers in standard ductwork, making installation straightforward.

• Type: Square, Parallel Blade
• Duct Size: 6 Inch x 6 Inch
• Blade Material: Extruded Aluminum
• Inclusions/Features: Spring Return, Mechanical Visual Position Indicator, Fail Safe, Normally Open Operation
• Motor: 24 Volt AC at 60 Hz, 8 VA
• Torque & travel: 71 Inch-Ounce; 90 Degree
• Temperature Rating: 40 to 140 °F
• Pressure Drop: < 0.0329 in WC at 800 FPM; Max Static Pressure 1 in WC
• Motor Timing: 30 Second (Power Open) / 10 Second (Spring Return)
• Wiring: M1 Power, M6 Common, M4 LED Indication (Optional)

Ideal for zone dampers in residential or light commercial HVAC, this ZD6X6TZ model helps optimize comfort, energy efficiency, and system longevity.
