Robertshaw 700-511 Gas Valve

Robertshaw 700-511 Gas Valve provides precise gas control with a 3/4 Inch nominal size for heating systems. Featuring female threaded x female threaded end connections and a thermostat actuator, it delivers reliable regulation for furnaces, boilers, and pool equipment.

This valve operates with a millivolt input of 250–750 millivolts and tolerates temperatures from -40 to 175 Deg F, with a 1/2 PSI pressure rating. The included inlet filtered screen helps prevent debris from affecting performance, supporting dependable operation in both residential and commercial installations.

Certified for safety and compliance, the valve is UL and CSA listed and RoHS compliant. It offers convenient wiring via screw or spade terminals and versatile connections, including a 1/4 Inch pilot tubing outlet, a straight-through side outlet, and a 2 Inch threaded reducer bushing.

• Nominal size: 3/4 Inch
• End connections: Female threaded x Female threaded
• Actuator: Thermostat
• Input rating: 250–750 millivolts
• Temperature range: -40 to 175 Deg F
• Pressure rating: 1/2 PSI
• Inlet: Filtered screen
• Pilot outlet: 1/4 Inch tubing
• Side outlet: Straight-thru
• Reducer bushing: 2 Inch threaded
• Capacity: 400,000 BTU/Hour
• Applications: Heating, furnaces to swimming pool
• Standards: UL, CSA; RoHS Compliant

Engineered for reliability and long service life, this valve is an excellent choice for new installations or replacements in demanding heating applications.
