Robertshaw 720-403 Gas Valve

The Robertshaw 720-403 Gas Valve is a durable dual shut-off magnet valve designed for reliable natural gas control. It features nominal size 1/2 inch x 3/4 inch with end connections that are female threaded on both the inlet and outlet, making it easy to integrate into existing gas lines. The valve operates on 24 V AC (50/60 Hz) at 0.5 A and performs across a wide temperature range from -40 to 175 F. With a pressure rating of 1/2 psi and a capacity of 150,000 BTU/hour, this unit delivers steady performance for residential and commercial gas applications. It includes an inlet filtered screen and regulator conversion kit and is RoHS compliant for environmentally conscious installations.

• Nominal size: 1/2" x 3/4"
• End connections: Female threaded x Female threaded
• Input: 24 V AC at 50/60 Hz, 0.5 A
• Temperature range: -40 to 175 F
• Pressure rating: 1/2 psi
• Capacity: 150,000 BTU/hour
• Pressure regulating setting: 3.5 inch WC (Natural Gas)
• Inlet filtered screen and regulator conversion kit included
• Pilot outlet: 1/4" tubing
• Side outlet: 1/2" female threaded
• Reducer bushing: 3/4" x 1/2" threaded
• RoHS compliant
• Terminal type: Screw/Spade
