Taco 0010-F3 Cartridge Circulator
Taco 0010-F3 Cartridge Circulator
Low stock: 1 left
Couldn't load pickup availability
SKU:4708
View full details
![Taco 0010-F3 Cartridge Circulator — New England Supply House spec card [NESH-SPEC-CARD-V2]](http://newenglandsupplyhouse.com/cdn/shop/files/spec-9033015394526.png?v=1782848331&width=1445)
The Taco 0010-F3 Cartridge Circulator is a compact, direct-drive, horizontal-mount circulator designed for residential and light commercial hydronic systems. With flexible suction and discharge options (3/4", 1", 1-1/4", 1-1/2" each), it supports medium-head, medium-flow circulation for radiant heating, indirect water heaters, and closed-loop setups.
Operating at 115 V AC, 60 Hz, this 1/8 HP PSC motor runs at 3,250 RPM to deliver a flow of 0–32 GPM and a discharge head of 0–10 ft, with a 150 PSI pressure rating. Built for durability, it features a cast iron casing, a ceramic shaft, and a non-metallic impeller, paired with a robust EPDM O-ring and gasket for dependable sealing. It is UL (Canada/US) and NSF/ANSI 372 lead-free compliant and intended for indoor use.
Applications include residential and light commercial hydronic/radiant heating, primary-secondary loops, indirect water heaters, chilled water cooling, and potable hot water systems.
- Low power consumption
- Aluminum stator housing
- Stainless steel cartridge
- Carbon bearing
- EPDM O-ring and gasket
- Flanged x Flanged end connections
- 3-year warranty from date of manufacture
Specifications
| Type | Compact, Direct Drive, Horizontal Mount |
|---|---|
| Pressure Rating | 150 PSI |
| Temperature Rating | 40 to 230 Deg F |
| Input Supply | 115 Volt AC at 60 Hertz 1-Phase 1.1 Amp |
| Flow Rate | 0 to 32 GPM |
| Power Rating | 1/8 HP |
| Application | Residential/Light Commercial, Medium-Head/Medium Flow Water Circulating, Hydronic/Radiant Heating, Primary-Secondary Loop, Indirect Water Heater, Chilled Water Cooling, Potable Hot Water System, Closed Loop System, Indoor |
| End Connection | Flanged x Flanged |
| Discharge Size | 3/4 Inch, 1 Inch, 1-1/4 Inch, 1-1/2 Inch |
| Suction Size | 3/4 Inch, 1 Inch, 1-1/4 Inch, 1-1/2 Inch |
| Speed | 3250 RPM |
| Discharge Head | 0 to 10 Foot |
| Standards | UL (Canada and US), NSF/ANSI 372 |
| Includes | Low Power Consumption, Aluminum Stator Housing, Stainless Steel Cartridge, Carbon Bearing, EPDM O-Ring and Gasket |
| Excludes | Mechanical Seal |
| Impeller Material | Non-Metallic |
| Impeller Design | Closed |
| Casing Material | Cast Iron |
| Motor Type | Permanent Split Capacitor, Impedance Protected |
| Shaft Material | Ceramic |
| Warranty | 3 Year from Date of Manufacture |
