Taco 0012SF Cartridge Circulator

The Taco 0012SF Cartridge Circulator is a compact, direct-drive cartridge circulator designed for residential and light commercial heating and cooling systems.

Built with a stainless steel casing, ceramic shaft, and non-metallic open impeller, it is a compact direct-drive design with a horizontal mount and 1-1/2 inch suction and discharge with flanged ends, delivering reliable flow with low power consumption.

Key specs include 0–52 GPM, 0–14.5 ft discharge head, 115V AC at 60 Hz (1-Phase, 1.33 A), 1/8 HP motor, 3250 RPM, 40–230°F operation, and a 150 PSI pressure rating.

Included features and build quality combine durability and efficiency:

• Compact direct-drive cartridge circulator for space-saving installations
• Horizontal mount with 1-1/2" suction and discharge fittings and flanged ends
• Stainless steel cartridge, ceramic shaft, and non-metallic open impeller for durable flow
• Low power consumption (1/8 HP) with 115V, 60 Hz input
• Flow up to 52 GPM and head to 14.5 ft; maximum 150 PSI
• Operating temperature range 40–230°F
• 3-year warranty from date of manufacture; lead-free, UL and NSF/ANSI 372 compliant

Ideal for residential and light commercial heating/cooling systems, high-flow/medium-head boiler setups, open loop, and fresh potable water installations.
