Taco 007-F5 Cartridge Circulator
Taco 007-F5 Cartridge Circulator
Low stock: 7 left
Couldn't load pickup availability
SKU:4722
View full details
![Taco 007-F5 Cartridge Circulator — New England Supply House spec card [NESH-SPEC-CARD-V2]](http://newenglandsupplyhouse.com/cdn/shop/files/spec-9033015460062.png?v=1782848333&width=1445)
Experience efficient flow with the Taco 007-F5 Cartridge Circulator. This compact, direct-drive cartridge circulator uses a wet-rotor design for reliable in-line, horizontal mounting in hydronic systems.
Designed for radiant heating, indirect water heaters, hydro air, and closed-loop cooling, it delivers dependable performance with low power consumption. The 1/25 HP motor runs on 115V AC at 60 Hz, spins 3,250 RPM, and handles 40–240°F temperatures up to 125 PSI.
Built to last, the Taco 007-F5 uses a ceramic shaft for wear resistance and a durable cast-iron casing. A stainless steel cartridge, carbon bearing, and EPDM O-rings ensure reliable performance in demanding boiler rooms and radiant installations.
- Flow up to 23 GPM with a 0–10 ft discharge head
- Suction and discharge sizes range from 3/4 in to 1-1/2 in; Flanged x Flanged ends
- Casing: cast iron; shaft: ceramic; impeller: non-metallic
- Includes steel stator housing, stainless steel cartridge, carbon bearing, EPDM O-ring and gasket
- Lead-free construction; UL (Canada/US) and NSF/ANSI 372 compliant
- Warranty: 3 years from date of manufacture; Applications include hydronic heating, radiant floors, indirect water heaters, hydro air, and closed-loop systems
Specifications
| Type | Compact, Direct Drive, In-Line, Wet Rotor, 1-Stage, Horizontal Mount |
|---|---|
| Pressure Rating | 125 PSI |
| Temperature Rating | 40 to 240 Deg F |
| Input Supply | 115 Volt AC at 60 Hertz 1-Phase 0.74 Amp |
| Flow Rate | 0 to 23 GPM |
| Power Rating | 1/25 HP |
| Application | Hydronic/Radiant Heating, Indirect Water Heater, Hydro Air Fan Coil, Chilled Fresh Water Cooling, Domestic Water Recirculation System, Closed Loop System, Indoor |
| End Connection | Flanged x Flanged |
| Discharge Size | 3/4 Inch, 1 Inch, 1-1/4 Inch, 1-1/2 Inch |
| Suction Size | 3/4 Inch, 1 Inch, 1-1/4 Inch, 1-1/2 Inch |
| Speed | 3250 RPM |
| Discharge Head | 0 to 10 Foot |
| Standards | UL (Canada and US), NSF/ANSI 372 |
| Includes | Low Power Consumption, Steel Stator Housing, Stainless Steel Cartridge, Carbon Bearing, EPDM O-Ring and Gasket |
| Excludes | Mechanical Seal |
| Impeller Material | Non-Metallic |
| Impeller Design | Closed |
| Casing Material | Cast Iron |
| Motor Type | Permanent Split Capacitor, Impedance Protected |
| Shaft Material | Ceramic |
| Warranty | 3 Year from Date of Manufacture |
