Taco 007E Circulator Pump

The Taco 007E Circulator Pump is a high-efficiency wet-rotor circulator designed for indoor hydronic baseboard and closed-loop systems. This 120V ECM permanent-magnet motor unit runs at 4830 RPM and delivers 0–16 GPM with a 0–10 ft discharge head, making it ideal for residential and light commercial setups.

Type High Efficiency, Wet Rotor, Horizontal Mount, with a rugged cast-iron casing, ceramic shaft, and a 6-inch lead; an integral flow check enhances reliability and simplifies installation. It uses a composite impeller in a closed design for quiet operation and long life.

• Voltage / Power: 120 VAC, 60 Hz, 0.54 A, 44 W
• Flow range: 0–16 GPM; Head: 0–10 ft
• End connections: Flanged x Flanged; Suction: 3/4" to 1-1/2"; Discharge: 3/4" to 1-1/2"
• Materials: Cast iron casing; ceramic shaft; composite impeller
• Motor: ECM permanent-magnet, thermally protected; 4830 RPM
• Inclusions: Composite stator housing, carbon bearing, ceramic thrust bearing, EPDM O-ring and gasket
• Warranty: 3 years from date of manufacture
• Standards: UL (Canada and US), FCC; indoor use in hydronic baseboard and closed-loop systems

With its compact size (6" L x 5" W x 6-3/8" H) and compatibility with standard flange connections, the Taco 007E Circulator Pump is a dependable choice for efficient home heating and radiant systems.
