Taco 008SF Cartridge Circulator

The Taco 008SF Cartridge Circulator is a compact, direct-drive circulator designed for residential and light commercial use. With a stainless steel cartridge, ceramic shaft, and open impeller, it delivers dependable performance and durability for everyday heating needs.

Flexible suction sizes (3/4 in, 1 in, 1-1/4 in, 1-1/2 in) and discharge options, plus end connections flanged x flanged, make it a versatile fit for hydronic heating, radiant in-floor/panel heating, open loop solar setups, water source heat pumps, and indoor domestic water recirculation systems.

• Flow rate: 0–14 GPM
• Discharge head: 0–16 ft
• Materials: Casing stainless steel; shaft ceramic; impeller non-metallic; open impeller design
• Electrical: 115 V AC, 60 Hz, 0.84 A, 1/25 HP, 3250 RPM
• Connections: Suction sizes 3/4", 1", 1-1/4", 1-1/2"; Discharge sizes 3/4", 1", 1-1/4", 1-1/2"; End connection flange x flange
• Inclusions: Low power consumption; steel stator housing; stainless steel cartridge; carbon bearing; EPDM O-Ring and gasket
• Warranty: 3 years from date of manufacture
• Applications: Hydronic heating; Radiant in-floor/panel heating; Open loop solar heating; Water source heat pumps; Domestic water recirculation
• Standards: UL (Canada/US); NSF/ANSI 372; Lead-Free
