Taco 009-F5 Cartridge Circulator

The Taco 009-F5 Cartridge Circulator is a compact direct-drive circulator designed for residential and light commercial hydronic systems. Built with a rugged cast-iron casing, a ceramic shaft, and a stainless steel cartridge, it delivers dependable flow and long life in a compact package.

Its 3/4", 1", 1-1/4", and 1-1/2" suction and discharge sizes and standard flange connections simplify installation across radiant floor heating, closed-loop solar heating, and other hydronic applications.

Operating at 115 V AC, 60 Hz, 1 phase, the 1/8 HP motor runs with low power consumption, delivering up to 10 GPM and 0–35 ft of head. Features such as an aluminum stator housing, EPDM O-ring and gasket, and a carbon bearing boost reliability and service life.

• Flow rate: 0–10 GPM
• Head: 0–35 ft
• Temperature range: 40–230°F
• Maximum pressure: 150 PSI
• Flange options: 3/4", 1", 1-1/4", 1-1/2"
• Inclusions: Aluminum stator housing, stainless steel cartridge, EPDM O-Ring and gasket, carbon bearing
• Warranty: 3-year from date of manufacture

Certified for UL (Canada/US) and NSF/ANSI 372 compliance; lead-free construction ensures safe, long-term operation in indoor residential and light commercial systems.
