White-Rodgers 1361-102 Hydronic Zone Valve

Hydronic Zone Valve The White-Rodgers 1361-102 Hydronic Zone Valve is a durable 3/4-inch, 2-wire valve designed for precise zoning in hydronic heating systems. This valve uses a corrosion-resistant stainless steel body to handle water temperatures up to 240°F and pressures up to 50 PSI, making it suitable for everyday heating duties.

With a compact footprint, it fits standard piping and maintains consistent flow with a Cv of 23.5. The unit operates on 24V AC (0.2 A) and includes a screw-terminal wiring panel for quick installation, plus a 24V AC 2-Amp auxiliary switch for expanded control options. The overall dimensions are 4-5/8 inches wide by 2-3/4 inches deep, with an end-to-end distance of 2-7/8 inches.

Open timing is 45 seconds and close timing 60 seconds, ensuring reliable, timed operation in residential and light commercial hydronic systems. Key features blend durable construction with versatile wiring and dependable performance across typical heating applications.

• Nominal size: 3/4 inch
• 2-wire control for simple wiring
• Corrosion-resistant stainless steel body
• Media: water; Temperature rating: 240°F; Pressure rating: 50 PSI
• Open: 45 seconds; Close: 60 seconds; Cv: 23.5
• 24V AC input (0.2 A); includes 24V AC 2-Amp auxiliary switch
• Screw-terminal wiring panel for easy connections
• Applications: hydronic system zoning in homes and light commercial settings
