White-Rodgers 3L09-8 Water Heater Drain Pan

The Water Heater Drain Pan from White-Rodgers 3L09-8 provides essential leak protection for your hot water system. Designed with a board-mount layout and Therm-O-Disc components, it delivers reliable limit-control performance for safe operation.

• Board-mount design for easy installation with standard heating controls
• Therm-O-Disc Type 36T / Style 612714 with a 1/2 inch bimetal disc for precise open/close temperature
• Length 3.12 inches; Mounting Type: Board; compatible with Therm-O-Disc Type 36T and Style 612714
• Voltage rating: 120/240/277 VAC (resistive); 120/240 VAC (inductive)
• Current ratings: 15 A @ 120 V (resistive); 13 A @ 240 V (resistive); 9.3 A @ 277 V (resistive); 5.8 A Full Load; 34.8 A Locked Rotor @ 120 V; 2.9 A Full Load; 13 A Locked Rotor @ 240 V (inductive)
• Power rating: 125 VA Pilot Duty
• Temperature ratings: Open 180°F, Close 140°F; Temperature setting on panel L180-40F
