White-Rodgers 586-105111 Power Contactor

The White-Rodgers 586-105111 Power Contactor is a reliable SPNO contactor with an isolated coil, designed for 12-Volt DC control. It delivers solid switching performance with an impressive 600-amp inrush capability, ideal for motor and load switching in tight control panels.

Built for continuous duty, this unit features vertical plane mounting, standard bracket style, and durable silver-alloy contacts for low resistance and long service life. The coil is insulated and rated for -40 to 149 degrees F, offering dependable operation across harsh environments. Dielectric strength is 600 V, ensuring solid isolation between coil and contacts.

• Configuration: SPNO with isolated coil
• Coil: 12 V DC, 21 Ω resistance
• Inrush current: up to 600 A
• Duty: Continuous
• Terminals: 4 for contacts; 2A- coil threads; termination sizes 5/16-24 UNF (contact) and #10-3 UNF (coil)
• Torque: 60 in-lb (contact terminals); 12–18 in-lb (coil terminals)
• Contact material: Silver alloy
• Temperature range: -40 to 149 °F
• Dielectric strength: 600 V
