White-Rodgers 586-108111 Power Contactor

White-Rodgers 586-108111 Power Contactor is a reliable SPNO isolated-coil device designed for demanding control circuits. Operating at 15 Volt DC with an impressive 600 A inrush, it provides fast, dependable switching in a compact package suitable for continuous duty applications.

Built for longevity, this contactor uses a durable silver alloy contact material and offers a dielectric strength of 600 V. It is designed for vertical-plane mounting with standard bracket hardware and supports robust, low-resistance connections. The coil resistance is 32.8 ohms, ensuring stable performance across a wide temperature range (-40 to 149 °F).

• Type: SPNO with isolated coil
• Coil voltage: 15 V DC
• Inrush current: 600 A
• Contact material: Silver alloy; dielectric strength 600 V
• Terminals: 4 terminals; 5/16-24 UNF-2A (contacts), #10-3 UNF-2A (coil)
• Mounting: Vertical plane; standard bracket
• Duty: Continuous
• Torque: 60 in-lb (contact terminals); 12–18 in-lb (coil terminals)
• Temperature range: -40 to 149 °F
