White-Rodgers 586-117111 Power Contactor

White-Rodgers 586-117111 Power Contactor is a high-performance DC coil SPNO contactor designed for demanding control circuits. This isolated-coil unit delivers reliable switching with a 36 Volt DC coil and a 200 Amp continuous current rating, making it ideal for commercial HVAC and industrial control panels. A robust SPNO contactor with an isolated coil, the White-Rodgers 586-117111 uses a 36V DC coil to switch up to 200A continuous, with a 600A inrush capability for startup surges.

• Type: SPNO with Isolated Coil
• Coil voltage: 36 VDC
• Inrush current: 600 A
• Current rating: 200 A continuous
• Duty cycle: Continuous
• Terminal type: 4
• Mounting: Vertical plane
• Threaded connections: 5/16" UNF-2A (contact); #10-3 UNF-2A (coil)
• Coil resistance: 189 Ω
• Contact material: Silver alloy
• Dielectric strength: 600 V
• Torque (contacts): 60 in-lb
• Torque (coil): 12–18 in-lb
• Dimensions: 3.69" L × 3.13" W × 2.19" H
• Temperature range: -40 to 149°F
