White-Rodgers 90-245 Air Conditioner Contactor

The White-Rodgers 90-245 Air Conditioner Contactor is a durable WR/RBM TYPE 122 two-pole device built for reliable HVAC operation. With dimensions of 2 Inch Width x 2.61 Inch Depth x 2.313 Inch Height, it fits tight panels while delivering dependable switching for cooling and heating systems.

This unit is rated for 120 Volt AC at 30 Amp, with a 6 VA coil running on 50/60 Hz, designed for continuous duty. Terminations include a pressure connector and double 1/4 inch quick-connects, and insulation uses high-quality thermosetting resin for longevity.

Operating in temperatures from -40 to 150 degrees Fahrenheit, the WR/RBM TYPE 122 contactor is UL listed and ARI standard compliant, ensuring safe integration into residential or commercial HVAC setups.

• WR/RBM TYPE 122 contactor for standard HVAC compatibility
• 2-pole design for reliable switching
• 120 VAC, 30 A load rating
• Coil frequency 50/60 Hz, 6 VA power
• Terminations pressure connector and double 1/4" quick-connects
• Compact dimensions 2" W x 2.61" D x 2.313" H
• Temperature range -40 to 150°F
• UL-listed and ARI standard compliant
