White-Rodgers 90-246 Air Conditioner Contactor

The White-Rodgers 90-246 Air Conditioner Contactor is a WR/RBM TYPE 122 2-pole control device designed for reliable operation in air conditioning and heating equipment. With a compact footprint measuring 2" W x 2.61" D x 2.313" H and a voltage rating of 208/240 VAC, it fits ARI-standard systems. UL-listed for safety, this contactor supports continuous duty across a wide temperature range (-40°F to 150°F) and is built to endure demanding service. It features pressure connectors and double 1/4" quick-connect terminations for straightforward wiring, and uses high-quality electric grade thermosetting resin for both the contact block and carrier to maximize insulation and longevity. The coil frequency is 50/60 Hz, making it compatible with most residential and light commercial controls.

• Voltage rating: 208/240 VAC
• Current rating: 30 A
• Pole configuration: 2-pole
• Terminations: Pressure connector and 1/4" quick-connect
• Material: Thermosetting resin contact block and carrier
• Operating temperature: -40°F to 150°F
• Coil frequency: 50/60 Hz
• Approval: UL listed
• Applications: Air conditioning and heating equipment
