Fireye Controls UV1A3 Ultraviolet Flame Scanner

Fireye Controls UV1A3 Ultraviolet Flame Scanner is a rugged UV flame detector engineered for safety-critical burner control. This UV flame scanner is designed to work with Flame-Monitor, BurnerLogix and Nexus systems, including M-Series, M-Series II, MicroM, FlameWorx, MB-2 and D-Series controls, delivering fast, reliable flame sensing across demanding industrial environments.

With a compact body (1.06 inch diameter x 2.53 inch length) and a quartz tube, the UV1A3 provides precise ultraviolet sensing while withstanding demanding conditions. The unit features a 560 VAC rating, 50/60 Hz, a 1/2 inch threaded straight connector, and 36 inch shielded leads, all housed in a NEMA 4X enclosure for moisture and dust resistance. It operates from -40 to 200°F and carries UL (Canada and US), FM, and CE approvals.

• Compatibility: Works with Flame-Monitor, BurnerLogix and Nexus systems (M-Series, M-Series II, MicroM, FlameWorx, MB-2, D-Series)
• Rugged enclosure: NEMA 4X enclosure for harsh industrial environments
• Sensor: Quartz tube ultraviolet flame detection
• Electrical: 560 VAC rating, 1/2" thread, 36" shielded leads
• Operating range: -40 to 200°F
• Certifications: UL (Canada/US), FM, CE
