Honeywell Commercial M7284C1000 Damper Actuator

The Damper Actuator delivers precise, modulating control for HVAC dampers and valves, built on the trusted Honeywell Commercial M7284C1000 platform. With a 120 VAC electric motor, it draws 0.24 A and delivers 23 W of power for smooth, reliable operation in commercial environments. The nominal 90-degree rotation and 150 inch-pounds of torque enable rapid, accurate positioning.

Its rugged die-cast aluminum body is enclosed to NEMA 3 standards, providing dependable performance in dusty or wet conditions. Clockwise rotation and a 4-20 mA control signal support seamless integration with building automation systems. The unit is designed for non-spring return duty and offers a 30–60 second timing range.

Operating temperature ranges from -40 to 150 deg F, expanding its suitability for diverse climates. Includes transformer, screw terminal adapter, and two auxiliary switches to simplify installation and integration. For mounting, choose foot mount and ensure secure connections with screw terminals. It is UL listed (Canada and US), CE, RoHS compliant.

• Modulating electric damper actuator for precise HVAC control
• Operates at 120 VAC with 0.24 A and 23 W
• 90° rotation with 150 in-lb torque for fast positioning
• NEMA 3-rated enclosure in die-cast aluminum
• 4–20 mA control signal; clockwise rotation
• Non-spring return; 30–60 second nominal timing
• Includes transformer, screw terminal adapter, and two auxiliary switches
• Foot mounting; screw terminal connections; UL listed; CE; RoHS
