Honeywell Commercial T775U2016 Electronic Remote Temperature Controller

Introducing the Honeywell T775U2016 Electronic Remote Temperature Controller—the versatile standalone temperature controller trusted for heating, cooling, boiler, and chiller systems. This universal controller offers robust control with a relay output, two SPDT contacts, and a rugged NEMA 1/IP65 enclosure, making it ideal for commercial environments. With a wide operating range, the setpoint spans -40 to 248°F and a differential of 1 to 150°F, enabling precise comfort and process control across different loads.

Designed for reliability, the T775U2016 supports two sensor inputs (1097 Ohm PTC at 77°F) and allows flexible wiring with conduit connections. It supports 50 Hz and 60 Hz power, and accepts multiple voltages (125/120/240 VAC) for various system configurations. The controller is UL (Canada/US), CUL, CE, and C-Tick approved, ensuring compliance and safety. It’s suitable for applications in heating, cooling, boilers, and chillers, with a maximum sensor distance up to 1000 feet.

• Two SPDT relay outputs for control of heating and cooling equipment
• Setpoint range: -40 to 248°F with 1–150°F differential
• Rugged enclosure: NEMA 1 / IP65 protection
• Two sensor inputs with 1097 Ohm PTC at 77°F
• Wide voltage support: 120/240 VAC, 125 VAC; compatible with 50/60 Hz
• UL, CE, C-Tick approvals for global installation
