Honeywell Thermal Solutions FSG Q7800A1005 Terminal Universal Wiring Sub-Base

Terminal Universal Wiring Sub-Base for Honeywell Thermal Solutions FSG Q7800A1005 offers a compact, panel-mount wiring base designed for 7800 Series Relay Modules and the S7830 Expanded Annunciator. This terminal sub-base delivers robust connections with a 22-terminal configuration and a durable NEMA 1 enclosure, making it ideal for control panels and process environments.

Engineered for easy installation and long-term reliability, it supports 22 terminals and uses standard terminal screws with a typical torque of 12 in-lbs (maximum 13 in-lbs). The enclosure measures 4-31/32" wide, 1-13/32" deep, and 4-31/32" high, providing a compact footprint for space-constrained panels. Operating and storage temperature ranges from -40 to 140°F, suitable for a wide range of industrial settings. This base carries UL and CSA approvals for added safety and compliance.

• Panel-mount compatibility with 7800 Series Relay Module and S7830 Expanded Annunciator
• 22-terminal configuration for versatile wiring
• NEMA 1 enclosure for indoor use
• Dimensions: 4-31/32" W x 1-13/32" D x 4-31/32" H
• Terminal screw torque: 12 in-lbs typical, 13 in-lbs maximum
• UL and CSA listed for safety and compliance
• Operational temperature: -40 to 140°F
