Resideo - Honeywell Home VR8300C4506 Solenoid Gas Valve

Solenoid Gas Valve for residential gas-fired appliances, the VR8300C4506 from Resideo - Honeywell Home delivers reliable control with a standing pilot operated, 1-stage, straight-through diaphragm design. This valve features 3/4 inch straight flange x 3/4 inch compression ports and runs on 24 Volt AC at 60 Hz for low-voltage operation, making it a versatile choice for modern gas systems.

Designed for safe, precise gas regulation, it handles 0 to 175°F ambient temperatures and supports up to 1/2 psi pressure. The unit mounts in any direction from upright, including vertically, and includes a pressure regulator setting of 3.5 in WC along with a 1/8 inch threaded tapping port for additional control. UL, CSA, and AGA standards ensure compliance for residential installations.

• Valving type: standing pilot operated, 1-stage, diaphragm
• Ports: 3/4" straight flange x 3/4" compression
• Electrical: 24 VAC, 60 Hz, low voltage
• Inclusions: (2) 3/4" x 1/2" reducer bushings, safety shut-off, step opening, manual valve, (2) automatic operator, pressure regulator and pilot adjustment
• Applications: residential gas fired appliance
• Dimensions: 4-1/16" W x 2-11/16" D x 5-3/8" H
• Capacity: 30–300 CFH
• Standards: UL, CSA, AGA
