Schneider Electric MA-5210 Damper/Valve Actuator

The Schneider Electric MA-5210 Damper/Valve Actuator is an ON/OFF, SPST, 2-position, linear actuator with spring-return operation for precise damper and globe valve control. It operates at 120 Volt AC (50/60 Hz), draws 10 W, and delivers 20 in-lb of torque, making it suitable for HVAC dampers and valve throttling in compact spaces.

Constructed with a NEMA 1 enclosure, the MA-5210 withstands standard facility environments from 0 to 140°F. Connection is made easy with a 4-foot color-coded lead and 1/2" conduit, and its compact footprint (3-1/4" diameter x 3-23/32" width x 6-3/4" height) fits tight actuator mounting. It carries UL 873, CSA, and CE approvals for dependable safety and compatibility in control panels and systems.

• Type: ON/OFF, SPST, 2-position, linear actuator with spring return
• Electrical: 120 VAC, 50/60 Hz, 10 W
• Torque: 20 in-lb
• Enclosure: NEMA 1; operating temperature 0–140°F
• Size: 3-1/4 in. diameter x 3-23/32 in. width x 6-3/4 in. height
• Connection: 4 ft color-coded lead with 1/2 in conduit
• Applications: Damper and globe valve control
• Certifications: UL 873, CSA, CE
