Schneider Electric MP-5210 Hydraulic Valve Actuator

The Schneider Electric MP-5210 Hydraulic Valve Actuator is a spring-return, proportional actuator designed for precise valve control in HVAC and industrial processes.

This compact unit measures 6-3/4 inches by 3-1/4 inches and offers a 2-inch stroke for damper operation or a 9/16-inch stroke for valve control when driven by 6–90 VDC. It runs on 120 VAC at 50/60 Hz and delivers power ratings of 12.9 W at 50 Hz and 11.7 W at 60 Hz. Built for durability, the lower housing is die-cast while the upper housing is painted steel, and a SPDT contact configuration provides flexible wiring. UL and CSA approvals ensure safety and compliance.

• Proportional hydraulic actuation for precise valve positioning
• Spring-return design offers reliable reset in demanding applications
• Stroke options: 2" (damper) or 9/16" (valve) at 6–90 VDC
• 120 VAC input with 50/60 Hz compatibility
• Durable construction: die-cast lower housing and painted steel upper housing
• SPDT contact configuration for versatile wiring
• UL and CSA approved for safety and compliance
