Siemens 2651022 Electrical to Pneumatic Control Valve

Electrical to Pneumatic Control Valve designed for precise signal-to-actuation, the Siemens 2651022 converts electrical input into reliable pneumatic motion. This solenoid-operated valve moves air through a 3-Way, 2-Position configuration with a rugged glass-filled thermoplastic body and a compact junction box for quick installation. It operates from 120 Volt AC at 60 Hertz, delivering up to 50 PSI and tolerating 0–100°F environments. UL and CUL listed, the unit sits in a sturdy NEMA 1 enclosure, ready for industrial applications. The 1/4" OD barbed tubing air connections and a mounting bracket with oval and open-ended holes simplify mounting in tight spaces and retrofit projects.

• Configuration: 3-Way, 2-Position
• Air Connection: 1/4 in. outer diameter barbed tubing
• Flow Rate: 600 SCIM; Cv 0.06
• Electrical: 120 VAC, 60 Hz; Power 6 VA
• Pressure/Temperature: 50 PSI max; 0–100°F
• Enclosure/Materials: NEMA 1; Glass-filled thermoplastic; Buna N, Copper, Stainless Steel
• Mounting: Bracket Type 1 Oval and Open-Ended Holes
• Standards: UL, CUL
