Argo ARM-6P Zone Switching Relay

Meet the Argo ARM-6P Zone Switching Relay — an electronically actuated control designed for precise, reliable zone management. The Argo ARM-6P Zone Switching Relay provides six independently switchable zones using SPST contacts, with expandable capability to grow with your system. Built for safety and durability, it adheres to CSA (Canada/US) and NEC standards, ensuring compatibility across North American installations. Powered by a 120 Volt AC transformer at 60 Hz, it offers a 30 VA power rating, ideal for motorized dampers, fans, or valves in HVAC or building automation setups.

The ARM-6P delivers efficient performance with a 1/3 HP motor rating and a thermostat current of 0.085 A, supporting precise actuation without overloading the circuit. Its electronic actuation provides smooth switching with minimal ghosting, while the SPST switch type keeps wiring simple and scalable. The unit is designed for easy installation and future expansion, making it a practical choice for retrofit projects and new installs alike.

• Zones: 6-zone platform with expandable options
• Actuation: Electronic actuation for precise control
• Switch: SPST contact configuration
• Power: 120 V AC, 60 Hz, 30 VA, supports up to 1/3 HP
• Standards: CSA and NEC compliant
• Thermostat current: 0.085 A
