GC Valves S211GF24N5EG5 Solenoid Valve

Solenoid Valve from GC Valves S211GF24N5EG5 is a robust 2-way, normally closed (NC) pilot diaphragm valve designed for reliable flow control in demanding systems. The brass-body unit features 3/4 inch female-threaded ports for simple integration with standard piping and a rugged NEMA 4/4X enclosure for indoor and outdoor use.

Powered by 24 Volt AC at 50 Hz, this valve supports vertical mounting and comes with a standard 24-inch lead length. It uses nitrile seals and is rated for ambient temperatures from 32 to 125°F. UL and CSA listings ensure compliance with essential electrical standards, while the design accommodates explosionproof configurations (NEMA 7) where required in hazardous environments.

• 2-way solenoid valve with normally closed (NC) operation
• Pilot diaphragm design for fast, tight shutoff
• Brass body with 3/4" female-threaded ports
• Enclosure: NEMA 4/4X rated, UL and CSA listed
• Power & mounting: 24V AC, 50 Hz; vertical mounting; 24" lead length
• Inclusions: metallic conduit, grommet, open frame, junction box (single/dual knockout); explosionproof (NEMA 7) option
• Seals & temp: nitrile seals; operating ambient 32–125°F
