GC Valves S211GH02T2EG5 Solenoid Valve

Solenoid Valve, GC Valves S211GH02T2EG5, delivers reliable 2-way control for steam systems. This 2-Way, Pilot Diaphragm valve features a brass body and a rugged NEMA 4/4X enclosure designed for harsh industrial environments. Port connections are 3/4" female threaded on both ends, making installation straightforward in existing piping. The valve handles steam media and operates on a 120V AC, 60 Hz supply with vertical mounting for easy integration into control panels. With non-stick seal material, it provides smooth operation and reduced wear in demanding applications. It is UL and CSA listed, ensuring compliance and safe operation in regulated facilities. A standard 24" lead length and robust construction support reliable performance across shifts, while the explosionproof capability (NEMA 7) expands use in hazardous locations.

• 2-Way Pilot Diaphragm valve for precise steam control
• Brass body with NEMA 4/4X enclosure for durability
• 3/4" female threaded port connections on both ends
• 120V AC, 60 Hz input; 24" lead length
• Explosionproof (NEMA 7); UL and CSA listed
• Vertical mounting; suited for steam media
• Non-stick seal material for smooth operation
• Inclusions: metallic conduit, grommet, open frame, junction box (single or dual knockout)
