Honeywell Thermal Solutions FSG V4062A1198 Fluid Power Gas Valve Actuator

The Honeywell Thermal Solutions FSG V4062A1198 Fluid Power Gas Valve Actuator delivers reliable, precise control for industrial gas valves and burners. This Hi-Lo-Off, standard, low-pressure actuator is designed for 120 Volt AC operation at 60 Hz, delivering 59.5 W for opening and 19 W for holding to ensure fast actuation with minimal energy use.

Its rugged die-cast aluminum body is protected by a NEMA 1 / IP30 enclosure, making it suitable for harsh plant environments. The actuator operates from -40 to 150 °F ambient and provides a 52° rotation, ideal for compact valve installations. With a maximum safe operating pressure of 5 PSI, it delivers dependable performance in gas valve applications. Opening time is 13 seconds, with closing in less than 1 second. Includes damper shaft and auxiliary switch. Certified for UL and CSA (Canada and US) approvals for added reliability. Ideal for industrial gas valve and burner control in commercial, institutional, and manufacturing settings.

• Type: Hi-Lo-Off, Standard, Low Pressure
• Voltage rating: 120 VAC
• Power rating: 59.5 W opening / 19 W holding
• Rotation: 52°
• Enclosure: NEMA 1, IP30
• Material: Die-Cast Aluminum
• Operating temp: -40 to 150 °F
• Applications: Industrial gas valve, gas burner
• Approvals: UL, CSA
• Max pressure: 5 PSI
• Timing: 13 s opening, < 1 s closing
• Includes: Damper Shaft, Auxiliary Switch
