Honeywell Thermal Solutions FSG V48A2169 Diaphragm Gas Valve

Diaphragm Gas Valve by Honeywell Thermal Solutions FSG V48A2169 delivers precise control for atmospheric boiler systems and commercial water or rooftop heaters. This NC (Normally Closed), slow-opening, fast-closing, straight-through, non-offset, solenoid-operated valve is sized at 1 inch nominal, featuring threaded end connections.

Built with a durable die-cast aluminum body, it performs reliably across 32–125°F and handles up to 1/2 psi. It is designed for Liquid Propane and Natural gas applications, powered by 120V AC at 60 Hz, drawing 0.13 A and consuming 9 watts.

• End connections: Threaded x Threaded
• Nominal size: 1 inch
• Body material: Die-Cast aluminum
• Temperature rating: 32–125°F
• Pressure rating: 1/2 psi
• Inclusions/installation: Ground terminal
• Application: Atmospheric boiler, commercial water/rooftop heater
• Standards: UL, CSA
• Overall dimensions: 4-5/16" W × 5" D × 6-1/16" H
• Fuel type: Liquid Propane, Natural
• Mounting position: Upright (Horizontal)
• Connection type: 6" lead wire
• Voltage/current/power: 120V AC, 60 Hz • 0.13 A • 9 W
• Valve timing: 5 seconds Open, 2 seconds Close
