Honeywell Thermal Solutions FSG V4943A1029 Diaphragm Gas Valve

The Honeywell FSG V4943A1029 Diaphragm Gas Valve delivers reliable ON/OFF control for commercial gas systems. This 1-1/4 inch, solenoid operated valve features a rapid-opening design and a straight-through, non-offset flow path for dependable performance.

Built with a durable die-cast aluminum body, it includes an automated position indicator and offers threaded end connections for easy installation. It operates at 120V AC, 60 Hz, draws 0.055 A, and provides a 1/2 psi pressure rating with a wide -40 to 150°F temperature range.

Ideal for atmospheric boiler, makeup air, rooftop heater, and duct furnace applications, UL and CSA listed, compatible with liquid propane and natural gas. Mounts upright and uses 1/4 inch spade terminals with two 30 inch leads.

• Nominal size: 1-1/4 in; End connections: Threaded x Threaded; End-to-end distance: 6 in
• Operation: ON/OFF, NC, rapid opening; Straight-through, non-offset flow
• End connections & leads: Threaded ends; 1/4 in spade terminals; (2) 30 in leads
• Electrical: 120V AC, 60 Hz; 0.055 A; 6 VA
• Mechanical: Die-cast aluminum body; Upright mounting
• Temperature & pressure: -40 to 150°F; 1/2 psi
• Fuel: Liquid Propane, Natural Gas
• Standards: UL, CSA
• Applications: Atmospheric boiler, makeup air, rooftop heater, duct furnace
