Honeywell Thermal Solutions FSG V4944L1024 Diaphragm Gas Valve

The Diaphragm Gas Valve from Honeywell Thermal Solutions, model FSG V4944L1024, delivers precise control for commercial heating and make-up air systems. This 2-Stage, rapid-opening, straight-through, non-offset, solenoid-operated valve ensures reliable operation in atmospheric boiler, rooftop heater, and duct furnace applications.

With a 1-1/4 inch nominal size and threaded end connections, it installs easily in tight spaces while maintaining robust durability. The automated position indicator, die-cast aluminum body, and compact 6 x 6 x 6-9/16 inch footprint make it a versatile choice for commercial setups.

Key specifications include -40 to 150 Deg F, 1/2 psi pressure rating, 120V AC 60 Hz supply, 0.077 A current, and 9 VA power, plus 6-second open and 2-second close timing. It supports liquid propane fuel and features 1/4 inch spade terminals with three 30 inch lead wires.

• Type 2-Stage, rapid-opening, solenoid-operated design for fast and reliable shutoff
• Automated position indicator for quick status checks
• Die-Cast aluminum body with 1-1/4" nominal size and threaded ends
• UL and CSA listed; compliant for safe commercial use
• Compact mounting: upright (horizontal), 6" W x 6" D x 6-9/16" H
• Electrical: 120V AC, 60 Hz; 0.077 A; 9 VA; spade terminal + three 30" leads
