Johnson Controls M9208-GGA-2 Electric Actuator

Johnson Controls M9208-GGA-2 Electric Actuator delivers precise proportional control for HVAC applications. The spring-return design and 24V AC/DC operation provide reliable damper and valve actuation across commercial environments.

With a robust 70 in-lb torque and a 95-degree travel, this actuator delivers smooth, accurate positioning and fast response. The rugged NEMA 2, IP54 enclosure protects internal components from dust and moisture, while SPDT limit switches ensure dependable end-stops for safe operation. Shaft options support round (5/16–5/8 in) and square (1/4–1/2 in) configurations, and a 3/8 in flexible metal conduit connection simplifies installation.

Power consumption is optimized for continuous operation: 7.9 W running / 5.5 W holding at 24V AC, or 3.5 W running / 1.9 W holding at 24V DC. This actuator is UL and CE approved, confirming compliance with global safety and performance standards.

• Type: Proportional Control
• Operation: Spring Return
• Voltage: 24V AC/DC (max 24V)
• Torque: 70 in-lb
• Travel: 95°
• Electrical: SPDT limit switch
• Enclosure: NEMA 2, IP54
• Shafts: Round (5/16–5/8 in) or Square (1/4–1/2 in)
• Connection: 3/8 in flexible metal conduit
• Applications: HVAC systems
• Certifications: UL, CE
