Rheem Furnace Parts 42-23116-06 Relay Sequencer

Relay Sequencer for Rheem furnaces delivers precise timing and reliable control. This 42-23116-06 unit is a versatile Rheem furnace part rated at 120/230/460 Volts and designed for On/Off-Delay timing to optimize fan and compressor cycles.

With a 2-pole DPST, NO contact configuration, it supports a 24 Volt heater and integrates easily with air handler setups. Compact at 2 inches long by 1.15 inches wide, it includes an angle bracket and two mounting holes for straightforward installation.

• Voltage Rating: 120/230/460 V
• Timing Mode: On/Off-Delay
• Contact Configuration: DPST, NO
• Timing Range: On 10–60 s; Off 30–160 s
• Pole: 2-pole design
• Heater Voltage: 24 V
• Dimensions: 2 in L × 1.15 in W
• Includes: angle bracket and two mounting holes
• Compatibility: ideal for air handler systems

Designed for reliable Rheem furnace repairs and upgrades, this compact relay sequencer provides durable control in a small footprint.
