Rheem Furnace Parts 46-22863-04 Control Transformer

Control Transformer for Rheem furnaces (model 46-22863-04) delivers a dependable 24V secondary output from a 120V primary input. This OEM-grade transformer operates at 50/60 Hz and provides 40 VA of power, making it a reliable replacement part for compatible furnace controls.

Built with Class 2 insulation and 1/4 inch insulated female quick-connect terminals, it is designed for OEM mounting and precise fit in standard Rheem furnace layouts. The compact, four-hole mounting pattern (2-3/16 in x 1-3/4 in) enables easy integration into existing control panels.

• Primary Voltage: 120V
• Secondary Voltage: 24V
• Power Rating: 40 VA
• Frequency: 50/60 Hz
• Insulation: Class 2
• Terminals: 1/4" insulated female quick-connect
• Mounting: OEM mount
• Hole Spacing: 2-3/16 in x 1-3/4 in
