Rheem Furnace Parts 47-23117-01 Temperature Control Limit Switch

Temperature Control Limit Switch for Rheem furnace parts, model 47-23117-01, delivers reliable auto reset in air handlers. This flangeless, surface-mount switch is designed for easy installation and enduring performance, with a gray disc-face for clear visibility in service panels. Operating between 80°F (open) and 70°F (close), it provides precise switching while tolerating small temperature swings of ±3°F to safeguard furnace operation and keep comfort steady.

Crafted for compatibility with typical Rheem HVAC systems, the switch features ¼-inch quick-connect terminals, a SPST, NC contact configuration, and a robust 230 VAC, 25 A rating. It is ideal for replacing worn or failed limit switches in air handlers and other components, ensuring safe auto-reset protection and long service life.

• Type: Flangeless Surface Mount, Auto Reset
• Temperature Range: 80°F Open / 70°F Close
• Contact Rating: 230 VAC, 25 A
• Contact Configuration: SPST, NC
• Connection Type: 1/4 Inch Quick Connect
• Application: Air Handler; Disc Face Type Exposed
• Temperature Tolerance: ±3°F Open/Close
• Color Code: Gray
